Fearture:
- -Excellent design for easy portable
- -Real time position tracking via 4G LTE and GPRS
- -History route from Web GPS platform or APP
- -GPS+WIFI+LBS locating
- -Call button for phone call direct
- -6-axis motion sensor and vibration motor
- -4MB (Buffer storage: GPRS 8000 PCS, SMS 400 PCS)
- -SMS for Google map link position
- -Various of alarm modes and call ways
- -Alarm SMS Head String and GPRS heartbeat interval
- -Geo-fence alarm/Low battery alarm
- -Flexible settings for SOS and call button
- -Waterproof IP67
- -Docking station charging
- -Rechargeable 1000 mAh battery for long standby
- -Black,Blue,Pink,White and Green color optional
.jpg)
Specifications:
| Items | Descriptions |
| Dimension | 65*46*17mm |
| Weight | 48g |
| GSM Module | Quectel EG915U, Cat 1 type |
| GPS Module | ZKW AT6558R |
| Charging Voltage | DC 5V/1A |
| Internal Battery | 1000mAh/3.7V Lithium ion battery |
| Full charging time | <2 hours 10 minutes |
| Power Consumption | Average 2.4mA standby current |
| Working hours | 5 minutes time interval 3 days 11 hours |
| Microphone | Built-in microphone |
| Speaker | Built-in speaker |
| Operating Temperature | -20℃~70℃ |
| Humidity | 5%~95% |
| Waterproof | IP67 (Testing condition: Immersed in 20cm depth water for 30 minutes) |
| LED Light | 2 LED lights indicate GPS/GSM/Power status |
| Button/Switch | 1 SOS button, 1 power button, 1 call button |
| Flash Memory | 4MB (Buffer storage: GPRS 8000 units, SMS 400 units) |
| Motion Sensor | 6-axis motion sensor |
| Vibration motor | Built-in, vibration reminder incoming call/button press |
| WiFi | 802.11 n (2.4 GHz) |
| Frequency Band E version: for Asia, Europe, Middle East, Africa countries |
2G GSM: 850/900/1800/1900 MHz |
| 4G FDD-LTE: B1/B3/B5/B7/B8/B20/B28 | |
| Frequency Band LA version: for Latin America and Australia countries |
2G GSM: 850/900/1800/1900 MHz |
| 4G FDD-LTE: B2/B3/B4/B5/B7/B8/B28/ B66 | |
| Frequency Band A version: for USA and Canada |
3G WCDMA: B2/B5 (1900/850 MHz) |
| 4G FDD-LTE: B2/B4/B12 | |
| GPS Sensitivity | -167dBm |
| GPS Start Speed | Cold start 30s Hot start 1s |
| Position Accuracy | 2.5m |
| Charging Port | 1 charging/ configuring magnetic connect port |
